LIFT Mk2 for Ex Machina Terra and GravityUpdated a month ago

SAFETY NOTES

• Do not hold, grab, pull, or lift the speaker support platform from inside the bolt access cutout. Risk of damage to the platform and injury could occur. Hold the platform firmly from below, never from the top cutout.
• Remove speakers from stands when moving or transporting.
• Components are heavy, do not drop them on yourself. Use caution when carrying stands.
• Speakers can be knocked off the stands. Use caution when moving around them.
• Be conscious of tripping hazards from cables.
• Only position the stands on solid, stable, and level surfaces.
• Ensure that all bolts are sufficiently tightened during the assembly process.
• Electrical shock hazard! Do not open the control box or columns. No user serviceable parts inside. For service needs, please contact us via our website.

ASSEMBLE LIFT Mk2 STAND

First, follow the instructions here to assemble and set up your LIFT Mk2 stand(s).

UNPACKING

Unpack all components and lay them out. Check that you have all of the following components:

In addition to the components for your LIFT speaker stand, each box should also contain the following, depending on the configuration you purchased:

LIFT Mk2 Speaker Stand for Ex Machina Terra (LIFT2-EM-TERRA)

and

LIFT Mk2 Expansion Kit for Ex Machina Terra (EXP-0001-V1-EMTERRAKIT)

• (1) Registration block
• (4) M5 x 16mm screws
• (1) 3mm Hex L Key



LIFT Mk2 Speaker Stand for Ex Machina Terra and Gravity (LIFT2-EM-TERRA-GRAVITY)

• (2) Registration blocks
• (8) M5 x 16mm screws
• (1) 3mm Hex L Key
• (1) Ex Machina Gravity Bracket
• (4) M6 8mm screws
• (4) Lock Washers
• (1) LIFT Gravity Platform
• (1) 16mm wrench

LIFT Mk2 Expansion Kit for Ex Machina Gravity (EXP-0002-V1-EMGRAVITYKIT)

• (1) Registration block
• (4) M5 x 16mm screws
• (1) 3mm Hex L Key
• (1) Ex Machina Gravity Bracket
• (4) M6 8mm screws
• (4) Lock Washers
• (1) LIFT Gravity Platform
• (1) 16mm wrench





ASSEMBLY PROCEDURE

Ex Machina Terra:

• Using your fingers, thread the screws through the registration block and into the bottom of your Ex Machina Terra speaker.
• Tighten screws using the L Key

• Place your Ex Machina Terra speaker on the LIFT speaker platform. Ensure that the alignment block is properly positioned in the alignment hole on the platform.

Ex Machina Gravity:

• Remove the nuts and washers from the two leveling feet on the outside of the base plate. Gravity subwoofers come in mirrored pairs: one for left; one for right. They should be positioned on the outside of the stand.
• Place the Ex Machina Gravity bracket on top of the baseplate; threading the leveling feet through the holes in the bracket.
• Tighten the bracket to the baseplate using the washers and locknuts as shown. Finger tighten and level first; use the included wrench to fully tighten once you are satisfied with the leveling.

• Using the (4) M6 bolts and (4) lock washers, attach the LIFT Gravity Platform to the bracket as shown. Tighten with the T Handle hex key that came with your LIFT stand:

• Using your fingers, thread the screws through the registration block and into the bottom of your Ex Machina Gravity speaker.

• Tighten screws using the L Key

• Place your Ex Machina Gravity speaker on the LIFT Gravity platform. Ensure that the alignment block is properly positioned in the alignment hole on the platform.

Proceed to the initialization steps outlined in the LIFT Mk2 Manual.
